48” Ultra Aluminum Fence 3-Rail UAS-101 TIGHT Picket Top design is perfect Small Dogs, Patios, Gardens, Accent fencing, Security, Children and Pets. This decorative fence looks great in any setting. Posts are 2" X 2" X 72" - Sections have 31-5/8" X 5/8" X 48" picket and 3 - 1-1/8"w X 1" h x 6 ft. long rails. 1-5/8" spacing
Can meet the Boca Code for pools with every picket extending through the top rail.
Please let us know if this is for a swimming pool. We will have it manufactured to meet the Boca code for swimming pools.
Can Be Manufactured in Flush Bottom rail or Standard Bottom rail.
At Fence City we do appreciate your order and look forward to helping you with your Ultra Aluminum Fence project.
This Ultra fence
is 48.00 inches high and meets the pool safety codes for most communities.
It is made of residential grade of aluminum and it comes in a picket structure
with 3 rails
and a 1.65 inch space between each picket
and Standard, Flush bottom.
Available in 7 colors.
This fence ships assembled.
This fence is sure to provide a decorative touch to your property.
We're here to help! If you have questions, feel free to call or email us.
Build an instant quote:
Select quantities from the parts below to build an instant quote. Click NEXT to see the discount applied to your quote.
PART
PRICE
QTY
SECTION
section sections are 6 foot in length
Sections or panels are the main component of any fence.
A rackable section can be adjusted to follow the slope of the landscape. Standard panels are fixed rectangles. Rackable panels allow the panel to be adjusted (more like a diamond shape) which allows the panel to adapt to the slope.
0.00
SECTION-ACCESSORY
quad-finial (for each 6 foot section and each gate leaf)
122.00
triad-finial (for each 6 foot section and each gate leaf)
122.00
POST
end post with regular cap and screws included
End posts are configured with holes only one one side of the post which allows the post to attach to one section of fence.
35.00
line post with regular cap and screws included
Line posts are configured with holes on opposite sides of the post which allows the post to attach to two sections of fence so that the fence continues.
35.00
corner post with regular cap and screws included
Corner posts are configured with holes on two adjacent sides of the post which allows the post to attach to two sections of a fence while changing the direction of the fence.
35.00
gate post - heavyweight with regular cap and screws included
Gate posts are reinforced to support the weight of a free-swinging gate.
60.00
blank post
35.00
blank heavyweight post
60.00
POST-ACCESSORY
ball-cap
Ball caps make an attractive addition to the top of each post. Prices shown are per ball-cap.
25.00
welded base flange with cover for line post (Post not Included)
To attach a post to concrete
75.00
welded base flange with cover for corner post (Post not included)
To attach a post to concrete
75.00
welded base flange with cover for end post (Post not included)
To attach a post to concrete
75.00
welded base flange with cover for gate post (Post not included)
To attach a post to concrete
75.00
welded base flange with cover for blank post (Post not included)
To attach a post to concrete
75.00
welded base flange with cover for blank heavyweight post (Post not included)
To attach a post to concrete
75.00
GATE
gate (3.00 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
544.35
gate (3.50 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
567.44
gate (4.00 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
583.68
gate (5.00 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
629.00
gate (6.00 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
665.19
double gate (6.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
1108.65
double gate (7.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
1129.46
double gate (8.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
1189.02
double gate (10.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
1270.25
double gate (12.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
1327.82
GATE-FEATURE
Add Arch to a single gate
Select this option to add an arch to a single gate.
200.00
Add Continuous Arch to a double gate
Select this option to add a continous arch across a double gate.
475.00
GATE-ACCESSORY
aluminum-self-closing-hinge (pair)
Aluminum self closing hinges are designed to bring the gate back to a closed position automatically.
58.97
magna-latch
Magna Latch gate latches are a premium upgrade to the standard latch used on a fence gate.
147.80
drop-rod
41.04
ez-lokk-latch
EZ LokkLatch gate hinge
48.80
CONNECTOR
wall-mount (qty 1 each) MUST ORDER 1 PER RAIL
Allows for a section of fence to be mounted to a structure instead of connected to a post.
15.00
adjustable-angle-bracket (qty 1 each) MUST ORDER 1 PER RAIL
Allows rails to be mounted at a straight-vertical or straight horizontal angle. Choose as many bracket(s) as your section has rails.
17.50
Hardware is not included with gates. Be sure to include hinges and latches in your order.
Specifications:
Style: UAS101R3
SKU: 48UAS101R3
Height: 48.00 inches
Minimum Height: 48.00 inches
Number of Rails: 3
Picket Spacing: 1.65 inches
Grade: Residential
Structure: Picket
Bottom: Standard,Flush
Pool safe: Yes
Colors:
Black
Bronze
White
Satin Black
Satin Bronze
Satin Khaki
Satin White
Photos:
The 48-inch Ultra Aluminum Fence UAS-101, featuring a tight picket spear top design, is a stylish and practical fencing solution ideal for small dogs, patios, gardens, accent fencing, security, children, and pets. With its decorative spear top and 1-5/8” picket spacing, it combines elegance and functionality to enhance any setting. The fence can also be manufactured to meet BOCA Code requirements for pool enclosures, ensuring safety and compliance when installed around swimming pools.
Key Features of the UAS-101 Fence
1. Spear Top Design
• Decorative and Secure: The spear top design adds a decorative touch while deterring climbing or unauthorized access.
• Timeless Aesthetic: Complements both traditional and modern landscapes, making it suitable for various property styles.
2. Tight Picket Spacing
• 1-5/8” Spacing: Ensures small dogs and other pets are securely contained.
• Safety for Children: The narrow spacing prevents children from squeezing through or getting stuck.
3. 3-Rail Construction
• Structural Strength: Three horizontal rails provide stability and durability, ensuring the fence maintains its shape over time.
• Dimensions: Rails measure 1-1/8” wide, 1” high, and 6 feet long, offering a sleek and sturdy framework.
4. Customizable Bottom Rail
• Flush Bottom Rail: Provides a seamless look, aligning the bottom rail with the ground for a clean and modern appearance.
• Standard Bottom Rail: Allows for a slight gap at the bottom, which improves drainage and reduces debris accumulation.
5. Durable Picket Construction
• Picket Dimensions: Each picket measures 31-5/8” x 5/8” x 48”, ensuring lightweight durability.
• Enhanced Strength: The spear pickets extend through the top rail for added security when BOCA compliance is required.
6. Aluminum Material
• Weather Resistant: Aluminum resists rust, corrosion, and fading, making it perfect for all climates.
• Low Maintenance: The powder-coated finish ensures the fence retains its color and durability without frequent upkeep.
• Eco-Friendly: Aluminum is recyclable, making it a sustainable fencing choice.
Applications for the UAS-101 Fence
1. Small Dogs and Pets
• The tight picket spacing ensures small pets, such as puppies or toy breeds, are securely contained while keeping them safe.
• Smooth aluminum edges eliminate sharp points, reducing injury risks for animals.
2. Patios and Gardens
• Creates a decorative barrier around patios and gardens, enhancing outdoor aesthetics.
• Prevents wildlife from damaging plants and landscaping.
3. Pool Enclosures
• When manufactured to BOCA Code compliance, the fence ensures safety around swimming pools with pickets extending through the top rail and self-closing gates.
• Meets local building codes for child safety in pool areas.
4. Accent Fencing
• Highlights walkways, pathways, or specific landscaping features, adding charm and sophistication to the property.
5. Security
• The spear top design acts as a visual and functional deterrent to unauthorized access, enhancing property security.
Gates and Hardware Options
1. Flat Top and Arched Gates
• Flat Top Gates: Simple and functional, offering a cohesive look with the fence’s clean lines.
• Arched Gates: Decorative and elegant, ideal for garden or patio entrances.
2. Self-Closing Hinges
• Automatic Closure: Ensures gates close securely after use, providing added safety and convenience.
• Durable Design: Made from high-quality materials, resistant to wear and weather.
3. Magna Latches
• Safety Locks: Ideal for pool enclosures, these latches are childproof and comply with safety standards.
• Easy Operation: Magnetic latches offer smooth functionality, ensuring secure and reliable locking.
Installation Guide
1. Tools Required
• Tape measure
• Level
• Drill or screwdriver
• Concrete mix for post footings
2. Installation Steps
1. Measure and Mark: Outline the fence area and mark post locations, ensuring posts are spaced properly (typically 6 feet
