This 54" tall Ultra Aluminum Fence 3-Rail UAS-100 Picket Top design is perfect for Patios, Gardens, Accent fencing, Security, Children and Pets. This decorative fence looks great in any setting. Posts are 2" X 2" X 84" - Sections have 15-5/8" X 5/8" X 54" picket and 3 - 1-1/8"w X 1" h x 6 ft. long rails.
Will not meet the Boca Code for a Pool
Can Be Manufactured in Flush Bottom Rail or Standard Bottom Rail.
At Fence City we do appreciate your order and look forward to helping you with your Ultra Aluminum Fence project.
This Ultra fence
is 54.00 inches high.
It is made of residential grade of aluminum and it comes in a picket structure
with 3 rails
and a 3.88 inch space between each picket
and Standard, Flush bottom.
Available in 6 colors.
This fence ships assembled.
Good for decorative, pets, home- this fence is sure to provide a decorative touch to your property.
We're here to help! If you have questions, feel free to call or email us.
Build an instant quote:
Select quantities from the parts below to build an instant quote. Click NEXT to see the discount applied to your quote.
PART
PRICE
QTY
SECTION
section sections are 6 foot in length
Sections or panels are the main component of any fence.
A rackable section can be adjusted to follow the slope of the landscape. Standard panels are fixed rectangles. Rackable panels allow the panel to be adjusted (more like a diamond shape) which allows the panel to adapt to the slope.
0.00
SECTION-ACCESSORY
butterfly-scroll (for each 6 foot section)
Butterfly Scrolls provide a decorative addition to the spaces between the pickets. Prices shown are to add enough butterfly scrolls to fill a section.
165.00
quad-finial (for each 6 foot section and each gate leaf)
122.00
triad-finial (for each 6 foot section and each gate leaf)
122.00
circle (for each 6ft section and each gate leaf)
Circles provide a decorative addition to the spaces between the pickets. Prices shown are to add enough circles to fill a section.
152.00
short-picket
Short pickets are placed at the bottom of a fence to reduce the spacing between the pickets to help protect smaller pets and young children.
90.00
POST
end post with regular cap and screws included
End posts are configured with holes only one one side of the post which allows the post to attach to one section of fence.
39.00
line post with regular cap and screws included
Line posts are configured with holes on opposite sides of the post which allows the post to attach to two sections of fence so that the fence continues.
39.00
corner post with regular cap and screws included
Corner posts are configured with holes on two adjacent sides of the post which allows the post to attach to two sections of a fence while changing the direction of the fence.
39.00
gate post - heavyweight with regular cap and screws included
Gate posts are reinforced to support the weight of a free-swinging gate.
70.00
blank post
39.00
blank heavyweight post
70.00
POST-ACCESSORY
ball-cap
Ball caps make an attractive addition to the top of each post. Prices shown are per ball-cap.
25.00
welded base flange with cover for line post (Post not Included)
To attach a post to concrete
75.00
welded base flange with cover for corner post (Post not included)
To attach a post to concrete
75.00
welded base flange with cover for end post (Post not included)
To attach a post to concrete
75.00
welded base flange with cover for gate post (Post not included)
To attach a post to concrete
75.00
welded base flange with cover for blank post (Post not included)
To attach a post to concrete
75.00
welded base flange with cover for blank heavyweight post (Post not included)
To attach a post to concrete
75.00
GATE
gate (3.00 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
365.66
gate (3.50 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
382.47
gate (4.00 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
398.15
gate (5.00 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
444.32
gate (6.00 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
478.23
double gate (6.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
747.84
double gate (7.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
772.64
double gate (8.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
827.64
double gate (10.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
900.89
double gate (12.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
965.01
GATE-FEATURE
Add Arch to a single gate
Select this option to add an arch to a single gate.
200.00
Add Continuous Arch to a double gate
Select this option to add a continous arch across a double gate.
475.00
GATE-ACCESSORY
aluminum-self-closing-hinge (pair)
Aluminum self closing hinges are designed to bring the gate back to a closed position automatically.
58.97
magna-latch
Magna Latch gate latches are a premium upgrade to the standard latch used on a fence gate.
147.80
drop-rod
41.04
lockable-drop-rod
102.60
ez-lokk-latch
EZ LokkLatch gate hinge
48.80
CONNECTOR
wall-mount (qty 1 each) MUST ORDER 1 PER RAIL
Allows for a section of fence to be mounted to a structure instead of connected to a post.
15.00
adjustable-angle-bracket (qty 1 each) MUST ORDER 1 PER RAIL
Allows rails to be mounted at a straight-vertical or straight horizontal angle. Choose as many bracket(s) as your section has rails.
17.50
Hardware is not included with gates. Be sure to include hinges and latches in your order.
Specifications:
Style: UAS100R3
SKU: 54UAS100R3
Height: 54.00 inches
Minimum Height: 0.00 inches
Number of Rails: 3
Picket Spacing: 3.88 inches
Grade: Residential
Structure: Picket
Bottom: Standard,Flush
Pool safe: No
Colors:
Black
Bronze
White
Satin Black
Satin Khaki
Satin White
Photos:
The 54” tall Ultra Aluminum Fence 3-Rail UAS-100, featuring a classic picket top design, is an elegant and durable fencing solution. Perfect for patios, gardens, accent fencing, security, children, and pets, this decorative fence enhances the functionality and beauty of any property. Built with high-quality aluminum, this fence is both lightweight and strong, designed to withstand weathering and everyday use. While this fence does not meet BOCA Code requirements for pools, it is an excellent choice for other fencing applications and can be customized with flush or standard bottom rails.
Product Specifications
1. Pickets:
• Dimensions: 15-5/8” x 5/8” x 54”
• The picket top design combines a traditional aesthetic with functional security by deterring climbing.
2. Rails:
• Dimensions: 1-1/8” wide x 1” high x 6 ft. long
• Includes 3 horizontal rails, providing stability and structural integrity.
3. Posts:
• Dimensions: 2” x 2” x 84”
• Engineered for strength and durability, these posts securely anchor the fence panels.
4. Material:
• Made from high-strength aluminum alloy that resists rust, corrosion, and weathering, making it ideal for outdoor use.
5. Finish:
• Powder-coated for a long-lasting, smooth finish that resists chipping, peeling, and fading.
6. Bottom Rail Options:
• Flush Bottom Rail: Creates a seamless, modern appearance by aligning the rail with the ground.
• Standard Bottom Rail: Leaves a small gap for drainage and reduces debris buildup, ideal for areas with uneven terrain.
Comparison to Other Fencing Options
1. Versatility
• 54” Height: Provides a balanced combination of visibility and containment, suitable for children, pets, and decorative applications.
• Picket Design: Classic and timeless, this style complements both modern and traditional landscapes.
• Alternative Materials: Unlike wood, which requires frequent maintenance, or steel, which is prone to rust, aluminum offers long-term performance with minimal upkeep.
2. Strength and Durability
• Aluminum fences are lightweight yet sturdy, designed to handle everyday wear and tear without bending or warping.
• Powder-coated finishes ensure protection against fading and chipping, outlasting painted or stained wood fences.
3. Customization
• Available in flush or standard bottom rails, making it adaptable to various landscapes and styles.
• Offered in multiple colors to match property aesthetics.
Installation Guide
Tools Required:
• Tape measure
• Level
• Drill or screwdriver
• Concrete mix for post footings
Step-by-Step Instructions:
1. Prepare the Area:
• Measure the perimeter of the area to be fenced and mark post locations (generally 6 feet apart).
2. Dig Post Holes:
• Holes should be 2-3 feet deep, depending on local soil conditions and frost lines.
3. Set Posts:
• Insert the posts into the holes and fill with concrete, ensuring they are level and aligned. Allow the concrete to cure fully before attaching panels.
4. Attach Fence Panels:
• Secure the fence panels to the posts using the provided mounting brackets, ensuring the rails and pickets are properly aligned.
5. Install Gates (if applicable):
• Attach gates to gate posts using self-closing hinges. Install Magna Latches or other hardware for secure and functional operation.
Applications
1. Patios and Gardens:
• Defines outdoor spaces while maintaining an open and inviting look.
• Protects landscaping from pets or wildlife.
2. Accent Fencing:
• Highlights pathways, flower beds, or fountains with a decorative touch.
3. Security and Safety:
• Keeps children and pets contained within a designated area while deterring unauthorized access.
Why Choose Ultra Aluminum Fences?
1. Durability:
• Engineered with premium aluminum alloy for rust and corrosion resistance.
• Powder-coated finish protects against weathering, ensuring long-lasting beauty.
2. Low Maintenance:
• Unlike wood or iron, aluminum requires no painting, staining, or frequent repairs, making
