The 60" tall tight picket Ultra Aluminum Fence 3-Rail UAS-101 TIGHT Picket Top design is perfect for small dogs, Patios, Gardens, Accent fencing, Security, Children and Pets. This decorative fence looks great in any setting. Posts are 2" X 2" X 84" - Sections have 31-5/8" X 5/8" X 60" picket and 3 - 1-1/8"w X 1" h x 6 ft. long rails. 1-5/8" Spacing
Will meet the Boca Code for pools
Can Be Manufactured in Flush Bottom or Standard Bottom Fence.
At Fence City we do appreciate your order and look forward to helping you with your Ultra Aluminum Fence project.
This Ultra fence
is 60.00 inches high and meets the pool safety codes for most communities.
It is made of residential grade of aluminum and it comes in a picket structure
with 3 rails
and a 1.65 inch space between each picket
and Standard, Flush bottom.
Available in 7 colors.
This fence ships assembled.
This fence is sure to provide a decorative touch to your property.
We're here to help! If you have questions, feel free to call or email us.
Build an instant quote:
Select quantities from the parts below to build an instant quote. Click NEXT to see the discount applied to your quote.
PART
PRICE
QTY
SECTION
section sections are 6 foot in length
Sections or panels are the main component of any fence.
A rackable section can be adjusted to follow the slope of the landscape. Standard panels are fixed rectangles. Rackable panels allow the panel to be adjusted (more like a diamond shape) which allows the panel to adapt to the slope.
0.00
SECTION-ACCESSORY
quad-finial (for each 6 foot section and each gate leaf)
122.00
triad-finial (for each 6 foot section and each gate leaf)
122.00
POST
end post with regular cap and screws included
End posts are configured with holes only one one side of the post which allows the post to attach to one section of fence.
39.00
line post with regular cap and screws included
Line posts are configured with holes on opposite sides of the post which allows the post to attach to two sections of fence so that the fence continues.
39.00
corner post with regular cap and screws included
Corner posts are configured with holes on two adjacent sides of the post which allows the post to attach to two sections of a fence while changing the direction of the fence.
39.00
gate post - heavyweight with regular cap and screws included
Gate posts are reinforced to support the weight of a free-swinging gate.
70.00
blank post
39.00
blank heavyweight post
70.00
POST-ACCESSORY
ball-cap
Ball caps make an attractive addition to the top of each post. Prices shown are per ball-cap.
25.00
welded base flange with cover for line post (Post not Included)
To attach a post to concrete
75.00
welded base flange with cover for corner post (Post not included)
To attach a post to concrete
75.00
welded base flange with cover for end post (Post not included)
To attach a post to concrete
75.00
welded base flange with cover for gate post (Post not included)
To attach a post to concrete
75.00
welded base flange with cover for blank post (Post not included)
To attach a post to concrete
75.00
welded base flange with cover for blank heavyweight post (Post not included)
To attach a post to concrete
75.00
GATE
gate (3.00 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
567.44
gate (3.50 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
589.96
gate (4.00 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
612.75
gate (5.00 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
665.19
gate (6.00 ft wide) hardware not included
A single free-swinging section that allows access through the fence.
712.63
double gate (6.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
1129.46
double gate (7.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
1189.02
double gate (8.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
1297.89
double gate (10.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
1360.31
double gate (12.00 ft wide) hardware not included
Two separate free-swinging sections to provide wider access through the fence.
1469.75
GATE-FEATURE
Add Arch to a single gate
Select this option to add an arch to a single gate.
200.00
Add Continuous Arch to a double gate
Select this option to add a continous arch across a double gate.
475.00
GATE-ACCESSORY
aluminum-self-closing-hinge (pair)
Aluminum self closing hinges are designed to bring the gate back to a closed position automatically.
58.97
magna-latch
Magna Latch gate latches are a premium upgrade to the standard latch used on a fence gate.
147.80
drop-rod
41.04
lockable-drop-rod
102.60
ez-lokk-latch
EZ LokkLatch gate hinge
48.80
CONNECTOR
wall-mount (qty 1 each) MUST ORDER 1 PER RAIL
Allows for a section of fence to be mounted to a structure instead of connected to a post.
15.00
adjustable-angle-bracket (qty 1 each) MUST ORDER 1 PER RAIL
Allows rails to be mounted at a straight-vertical or straight horizontal angle. Choose as many bracket(s) as your section has rails.
17.50
Hardware is not included with gates. Be sure to include hinges and latches in your order.
Specifications:
Style: UAS101R3
SKU: 60UAS101R3
Height: 60.00 inches
Minimum Height: 60.00 inches
Number of Rails: 3
Picket Spacing: 1.65 inches
Grade: Residential
Structure: Picket
Bottom: Standard,Flush
Pool safe: Yes
Colors:
Black
Bronze
White
Satin Black
Satin Bronze
Satin Khaki
Satin White
Photos:
The 60” tall Ultra Aluminum Fence 3-Rail UAS-101 with its tight picket top design is one of the most popular styles for swimming pools and security. Its combination of elegant aesthetics, superior craftsmanship, and functional safety makes it ideal for small dogs, patios, gardens, accent fencing, and protecting children and pets. Designed to meet BOCA Code requirements for pools when manufactured with a flush bottom rail, this fence is a reliable and stylish choice for homeowners seeking safety and beauty in one package.
Specifications for the Ultra Aluminum Fence
1. Fence Dimensions:
• Height: 60 inches (5 feet) for superior containment and pool safety.
• Pickets: 31-5/8” x 5/8” x 60”, with 1-5/8” spacing, providing a secure barrier for small pets and preventing climbing.
• Rails: 1-1/8” wide x 1” high x 6 ft. long, ensuring structural stability and a polished look.
• Posts: 2” x 2” x 84”, offering strong and stable support.
2. BOCA Compliance:
• When manufactured with a flush bottom rail, this fence meets all BOCA Code requirements for pool enclosures, ensuring safety for children and pets.
3. Material:
• Made from high-strength aluminum alloy, the fence is lightweight, durable, and resistant to rust and corrosion, making it perfect for outdoor use.
4. Finish:
• Powder-coated for a smooth, durable surface that resists chipping, peeling, and fading.
• Available in multiple colors, including black, bronze, white, green, and beige, allowing for customization to match any property.
Why Ultra Aluminum Fences Outperform the Competition
1. Material Quality:
• Ultra Aluminum: Uses high-strength aluminum alloys that resist bending, warping, and rusting, ensuring long-term durability.
• Competitors: Imported fences often use thinner, lower-grade aluminum that is prone to denting and corrosion.
2. Finish and Coating:
• Ultra Aluminum: Features a powder-coated finish applied using a cutting-edge process that ensures even coverage and long-lasting durability.
• Competitors: Many imported fences use inferior paint or coatings that chip, peel, or fade after just a few years of exposure.
• Warranty: Ultra Aluminum offers a limited lifetime warranty, while competitors rarely provide comparable guarantees.
3. Engineering and Construction:
• Ultra Aluminum fences are precision-engineered for consistent sizing, strength, and appearance. Competitors often suffer from poor manufacturing standards, leading to misalignments and weaker joints.
Gates, Construction, and Hardware
1. Gate Construction:
• Welded Corners: Ultra Aluminum gates feature precision-welded corners for superior strength and durability, preventing sagging or misalignment.
• Reinforced Rails: The gates are built with the same high-quality aluminum as the fence panels, ensuring they maintain their shape and performance over time.
2. Hardware:
• Self-Closing Hinges: Adjustable hinges automatically close gates, providing added convenience and security, especially for pool enclosures.
• Magna Latches:
• Childproof Design: These magnetic latches are tamper-proof and easy for adults to operate, ensuring that gates remain securely closed.
• Durability: Made from corrosion-resistant materials, Magna Latches maintain reliable performance even in wet or humid conditions.
3. Gate Design Options:
• Flat Top or Arched Designs: Both options are available to match your fence’s style, adding elegance and functionality to your property.
• Powder-Coated Finish: Gates are finished to match the fence, ensuring a cohesive and polished appearance.
Benefits for Swimming Pools and Security
1. BOCA Compliance:
• Meets pool safety standards when manufactured with a flush bottom rail, creating a secure barrier to prevent unsupervised access.
2. Child and Pet Safety:
• The 1-5/8” picket spacing ensures small pets cannot escape and prevents children from climbing.
3. Strength and Durability:
• The aluminum construction and welded gate corners resist wear and tear, en
